Export Compact Small Soundproof Office Phone Booth For 1 Person

Advantages of using a small office phone booths

1.Strong privacy:Provide an independent and closed space to avoid external interference and ensure the privacy of calls or work content.

2.Good sound insulation:Use high-quality sound insulation materials to effectively isolate external noise and ensure clear calls, suitable for telephone conferences or private conversations.

3.Efficient space utilization:Suitable for environments with limited space, small size, small footprint, can be flexibly placed in office buildings, airports, shopping malls and other places.

4.Improve work efficiency:Provide a quiet and focused workspace, reduce surrounding interference, improve personal work and communication efficiency, especially suitable for remote office and video conferencing.

5.Environmental protection and energy saving:Use environmentally friendly materials and low energy consumption design to meet the needs of sustainable development and suitable for modern green office concepts.

Detailed parameters of small office phone booths

1.Dimensions:

External dimensions :	1000x1000x2300 mm
Inner dimensions:	880 x 895 x 2150 mm
Floor area:	0 .79 m²
Table dimensions:	50 x 30 cm
Table height:	74 cm
Door dimensions:	90 x 230 cm – Reversible
Door free passage area:	88 cm
Fixed base:	Integrated adjustment levellers for easy interiorinterior access

2.materials:

Structure:	Extruded aluminum proﬁle glass frame and 1 . 0 mm cold- pressed steel plate , Interior structural frames of the panels made of 50x30x1 . 5mm galvanized steel tube . With 40mm PET thick and a density of 2200 gr/ m2 .
External cladding:	1 .0 thickness cold-pressed waterproof and rust-proof steel plate , more durable than melamine particle board panel .
Interior cladding:	PET ECO 9mm panel y upholstered. Bottom panels with ventilation grille of sheet steel e = 1 .5mm .
Roof coating:	Aluminum frame with 5 cm thick sound – absorbing cotton in the middle and 9mm PET ECO covering above and below.
Floor covering:	18 m m thic k ness M DF a nd high q uality soungproof carpet .
Tabletop:	Melamine chipboard table top e = 19mmLeg m a d e of l a m i n at e d a n d pi c kl e d st e e l tubing110x50 cm .

3.Technical information

Lighting :	2 longitudinal linear LED 8.6W-12V – 520mm;Daylight 4000K Simultaneous activation together with fans viapresence sensor.
Ventilation:	2 impellers in front + 4 extractors in roof.Ultra-thin + ultra-quiet fresh air exhaust fan speed: 750/1200 RPM ventilation, fan volume: 89/120 CFM average ventilation 110M3/H.
Acoustics:	Global Speech Reduction – ISO 23351-1:2020 TypeA (35 -40db)
Connectivity:	1 pcs 110v-220v 5-hole socket1, USB socket1, 1- position switch*Light and exhaust independent switch control.Connecting cablefrom cabinet: 2.5 m linear0.5 mL to GST18 connector + 2 mL from connectorto plug head.
TV bracket:	Optional bracket for mounting screens withunivers al VESA 100 and 200 + 1 CS 120v-220v Max. size: 43” // Max. weight: 15 Kg
Flame retardant:	Elements certiﬁed B-s1-d0 against reaction to ﬁre- Standard EN 13501-1 + A1:2013

Application of small office phone booths

1.Home: Provide a quiet work or study space to avoid family noise interference.
2.Airport: Provide passengers with a quiet call area, suitable for business calls or video conferencing.
3.Station: Provide a quiet call space while waiting, suitable for remote work or rest.
4.Hospital: Provide a private communication space for patients’ families and doctors to avoid noise interference.
5.Hotel: Provide guests with a quiet private call area, suitable for business video conferencing or email processing.
6.Shopping mall: Provide customers with a private call space, suitable for quick communication or rest.

Configuration options of solo pods

10mm high-strength film tempered glass, door opens outwards, B. Interlayer: sound-absorbing material, sound insulation material, 9mm sound insulation environmentally friendly board.
Ultra-thin + ultra-quiet fresh air exhaust fan, speed: 750/1200 RPM, air volume: 89/120 CFM, average air exchange volume 110M3/H.
Contains anti-static and anti-fouling low-loop pile carpet.
Built-in 4000K natural light.
Furniture: high-quality fixed table.
Power system: five-hole socket * 1, USB socket * 1, 1-speed switch * lighting, exhaust independent switch control.
Equipped with adjustable feet, movable wheels, fixed foot cups.
High-quality door locks can be selected according to customer requirements.
Colors can be customized according to customer requirements.

Why choose Tctcpod small office phone booths?

High-quality soundproofing: The pods are constructed with highly soundproofing materials, ensuring conversations remain private and external noise is minimized.
Customizable design: Tctcpod offers a range of customization options, allowing businesses to choose the size, color, and configuration that best suits their space and brand image.
Sustainability: Many of the materials used in the Tctcpod pods are environmentally friendly, in line with the growing emphasis on sustainable business practices.
Integrated technology: The pods are equipped with necessary technology such as power outlets, lighting, and ventilation to support an efficient work environment.
Easy installation: The pods are designed to be easy to install and can be set up without extensive construction.
Quality service: Tctcpod supports wholesale, retail, OEM/ODM/OBM, customized services.

FAQ (Frequently Asked Questions)for small office phone booths

Q1: How is the sound insulation effect of the telephone booth?
A1: The single-person small telephone booth adopts high-quality sound insulation materials, which can effectively isolate external noise and ensure clear calls without interference.

Q2: Does the single-person small telephone booth need regular maintenance?
A2: The telephone booth has a simple structure and low maintenance cost. Routine cleaning and inspection are sufficient to ensure that the ventilation and lighting systems are working properly.

Q3: Is the telephone booth suitable for long-term use?
A1: Yes, the telephone booth is designed with comfort and functionality in mind. It is equipped with comfortable seats and appropriate lighting inside, which is suitable for long-term use.

Q4: What are the power requirements of the telephone booth?
A4: Single-person small telephone booths are usually equipped with power sockets to support the charging needs of devices such as laptops and mobile phones.

Q5: Can the appearance or function of the telephone booth be customized?
A5: Tctcpod provides customized services. It can design the appearance, size, internal facilities, etc. of the telephone booth according to customer needs to meet the needs of different places.
